Product Summary

The VN0300M is an N-channel enhancement mode MOS transistor.

Parametrics

VN0300M absolute maximum ratings: (1)drain-source voltage, VDS: 30V; (2)gate-source voltage, VGS: ±30V; (3)continuous drain current, ID: 0.67A at TA=25℃; 043A at TA=100℃; (4)pulsed drain current, IDM: 3A; (5)power dissipation, PD: 1W at TA=25℃; 0.4W at TA=100℃; (6)operating junction & storage temperature range, TJ, Tstg: -55 to 150℃; (7)lead temperaure, TL: 300℃.

Features

VN0300M features: (1)V(BR)DSS: 30V; (2)rDS(ON): 1.2Ω; (3)ID: 0.67A; (4)package: TO-237.

Diagrams

VN0300M circuit diagram
