Product Summary
The BF872 is a PNP high-voltage transistor. It is used in in class-B video output stages of colour television receivers.
Parametrics
BF872 absolute maximum ratings: (1)VCBO collector-base voltage: -300 V; (2)VCEO collector-emitter voltage: -300 V; (3)VEBO emitter-base voltage: -5 V; (4)IC collector current (DC): -50 mA; (5)ICM peak collector current: -100 mA; (6)IBM peak base current: -50 mA; (7)Ptot total power dissipation: 1.6 W; (8)Tstg storage temperature: -65 to +150 ℃; (9)Tj junction temperature: 150 ℃; (10)Tamb operating ambient temperature: -65 to +150 ℃.
Features
BF872 features: Low feedback capacitance.
Diagrams
